High Durability Stainless Steel Railing Balusters With Glass Clamps

High Durability Stainless Steel Railing Balusters With Glass Clamps

  • High Durability Stainless Steel Railing Balusters With Glass Clamps
  • High Durability Stainless Steel Railing Balusters With Glass Clamps
High Durability Stainless Steel Railing Balusters With Glass Clamps
Product Details:
Place of Origin: Qingdao, China
Brand Name: Compass
Certification: ISO 9001, SGS
Model Number: P201
Payment & Shipping Terms:
Minimum Order Quantity: 50pcs
Price: Negotiable
Packaging Details: Bag + Carton + Plywood case
Delivery Time: 30-40days according to quantity
Payment Terms: L/C, T/T, Western Union, D/A, D/P
Supply Ability: 5000pcs per month
Contact Now
Detailed Product Description
Name: Raiing Baluster With Glass Clamps For Balcony Glass Thickness: 6, 6.76, 8, 8.76, 10, 10.76, 12, 12.76mm
Available Clamp: 40*50, 45*63, 45*45, 52*52, 55*55mm Height: 900mm - 1200mm
Material: AISI304, AISI316 Surface: Brushed(satin) Or Polished(mirror)
High Light:

stainless steel banister handrail


stainless steel stair balustrade

Stainless Steel Raiing Baluster with Glass Clamps for Balcony Glass Balustrade
High Durability Stainless Steel Railing Balusters With Glass Clamps 0

Features & Applications.


Qualified V2A ones are used indoor, V4A ones are used outdoor with better corrosion protection performance. The top saddle could be flat for square tube or round for 33.7mm, 38.1mm, 42.4mm, 48.3mm or 50.8mm pipes according to needs. Surface could be brushed(satin) or polished(mirror).


Different shape glass clamps could be choosen.Available glass clamps are D shape including 40*50mm, 45*63mm, or square shape - 45*45mm, 52*52mm, 55*55mm, then the glass could be 6mm, 6.76mm, 8mm, 8.76mm, 10mm, 10.76mm, 12mm, 12.76mm with different sizes. The body of the post can be 33.7mm, 38.1mm, 42.4mm, 48.3mm, 50.8mm or customized sizes according to needs, and general  total height is 900mm - 1200mm.


These posts are widely used in staircase, balcony, terrace, handrails, pool fence, stairs, gardens.


Used in both residential and commercial applidations, the glass railing systems allow you to showcase the view, rather than hide it.


Our system installs on site with no welding required – simply glue, drill and tap the pieces into place. Available in type AISI304 and AISI316 for either interior or exterior installation.


This is designed for both indoor and outdoor uses, easily accommodated glass. From office buildings to apartment complexes, balconies to separations, no welding required.






304 is the basic chromium-nickel austenitic stainless steel and has been found suitable for a wide range of applications. It is the most readily available in a variery of prodcut forms. This grade is easy to form and fabricate with excellent resistance to corrosion.


316 offers more corrosion-resistance through the addition of molybdunum. This grade is desirable where the possibility of severe corrosion exists, such as heavy industrial atmospheres and marine environments.


316L is the low carbon version of 316.


High Durability Stainless Steel Railing Balusters With Glass Clamps 1

Bussiness Scope of Compass.


Stainless steel railing balusters, frameless glass balustrade, slot tube balustrade, cable railings, wooden handrails and other fittings as glass clamps, brackets, etc..


General terms.

- Lead time: 30-50days according to order quantities.

- Payment term: T/T 30% deposit, 70% balance payed according to the documents copy.

- Departure port: Qingdao or other ports according to needs.

- Delivery term : FOB, CIF, CFR, DDU, DAP.

Customized dimensions are welcomed too.

Item NO.P201
Diameter33.7mm, 38.1mm, 42.4mm, 48.3mm, 50.8mm
Thickness1mm, 1.5mm, 2mm, 2.6mm or according to requirements
Height900-1200mm according to needs
Support Flat or round for 33.7mm-50.8mm tube
MaterialSS304 / SS316 /SS316L
Surfacesatin(brushed 320) / mirror
Available glass clamps40*50, 45*63, 45*45, 52*52, 55*55mm
Glass thickness6mm, 6.76mm, 8mm, 8.76mm, 10mm, 10.76mm, 12mm, 12.76mm
Production time35-45days according to quantities
PackingBag + carton + pallet
