Adjustable Tube Mount Handrail Support for Stainless Steel Outdoor Railings

Adjustable Tube Mount Handrail Support for Stainless Steel Outdoor Railings

  • Adjustable Tube Mount Handrail Support for Stainless Steel Outdoor Railings
  • Adjustable Tube Mount Handrail Support for Stainless Steel Outdoor Railings
Adjustable Tube Mount Handrail Support for Stainless Steel Outdoor Railings
Product Details:
Place of Origin: Qingdao, China
Brand Name: Compass
Certification: ISO 9001, SGS
Model Number: 536
Payment & Shipping Terms:
Minimum Order Quantity: 100pcs
Price: Negotiable
Packaging Details: Bag + Box + Carton + Pallet
Delivery Time: 30-40days according to quantity
Payment Terms: L/C, T/T, Western Union, D/A, D/P
Supply Ability: 10000pcs per month
Contact Now
Detailed Product Description
Product Name: Adjustable Tube Mount Handrail Support Bar: 14mm / 25mm
Height: 30-80mm Adjutable Type: Tube Mount
Base: Flat Or Round For 33.7-50.8mm Tubes Packing: Bag + Inner Box + Carton + Pallet
High Light:

stainless steel handrail fittings

,

stainless steel balustrade fittings

Adjustable Tube Mount Handrail Support for Stainless Steel Outdoor Railings



Item NO. Top saddle Base Rod Height
536.000 flat flat  14mm/ 25mm 30 - 80
536.337 33.7mm for 33.7mm round tube 14mm/ 25mm 30 - 80
536.381 38.1mm for 38.1mm round tube 14mm/ 25mm 30 - 80
536.424 42.4mm for 42.4mm round tube 14mm/ 25mm 30 - 80
536.483 48.3mm for 48.3mm round tube 14mm/ 25mm 30 - 80
536.508 50.8mm for 50.8mm round tube 14mm/ 25mm 30 - 80



Remarks.



The top saddle and base can work with the same pipes or in different radian for tubes in different diamters



Adjustable Tube Mount Handrail Support for Stainless Steel Outdoor Railings 0



General information.



1. Material is in SS304 (V2A) or SS316 (V4A).

2. Surface could be brushed(satin) or polished(mirror) according to requirements.

3. Available top saddle is 33.7mm, 38.1mm, 42.4mm, 48.3mm or 50.8mm.

4. The base could be flat or round for 33.7mm, 38.1mm, 42.4mm, 48.3mm or 50.8mm.

5. Customized dimensions are welcomed too.

6. Lead time : 35-45days according to order quantity.

7. Packing : Bubble bag per piece, 10pcs in a inner box, 10boxes in a carton, with pallet outside.

8. Delivery term : FOB, CIF, CFR, DDU, DAP.

9. Departure port: Qingdao or according to needs.

10. Payment term: T/T30% as deposit, 70% payed according to Bill of Lading.



Application.



This adjutable tube-tube bracket can be used as pipe support in kinds of invironments, AISI304 ones are for interior designs, AISI316 and AISI316L ones are used in exterior designs. They can work well in stairs, staircases, balcony, terrace, ect.



Adjustable Tube Mount Handrail Support for Stainless Steel Outdoor Railings 1
